LPA000-03480-1PE-0615-FO06 Large Volume Series Slip Ring,designed for onshore cable winches. This slip ring is designed to provide reliable power and signal transmission in typical harsh environments. With its rugged design and high-quality materials, it ensures optimal performance and service life. This product has a current of 480A and has a continuous batch. JINPAT also has a similar product that is customized for customers over 700A.
Features
Circuit Capacity:
Number of Circuits: 3/1/6, providing Onshore Cable Winch for power and signal needs in construction machinery.
Electrical Insulation:
Insulation Resistance:
Power Ring: ≥100MΩ@2500VDC, ensuring high insulation and safety.
Signal Ring: ≥100MΩ@250VDC, maintaining reliable signal integrity.
Premium Contact Materials:
Contact Material: Utilizes high-end copper carbon brushes and precious metals, ensuring excellent conductivity, durability, and low maintenance.
Robust Design:
Specifically designed for cranes used in construction, providing durable and reliable operation even in harsh environments.
Versatile Application:
Suitable for various Onshore Cable Winch applications, offering a versatile solution for complex power and signal transmission requirements.
LPA000-03480-1PE-0615-FO06 slip ring is the ideal choice for Onshore cable winch, providing a reliable, high-performance solution that ensures seamless power and signal transmission in challenging conditions.
Electronic & Electric |
Mechanical |
|||
| Circuits | Total | 3/1/6CKT |
Working Speed |
0~30rpm |
| Detail |
480A*3/PE*1（P） 15A*6（S） |
A hole diameter |
/ |
|
Rating Voltage |
6600VAC/220V | Contact Material |
High-end Copper Graphite /Precious Metal |
|
Dielectric Strength |
power ring: ≥30000VAC@50Hz signal ring: ≥500V@50Hz |
Shell Material |
SUS316(Q235)Spraying RAL7035 |
|
Insulation Resistance |
power ring: 100MΩ2500VDC |
Lead Wire Length |
/ | |
Environment |
Remarks |
|||
Working Temperature |
-20°C~+45°C |
Application |
Onshore Cable Winch |
|
Working Humidity |
≤95%RH |
|||
IP |
IP56 |
Other |
/ | |
For more customized solutions, please feel free to contact us at any time!
